| Main Feature | ||
| Type | Fiber Switch | |
| Ports | 8*1000Base-X SFP fiber ports (Data) 2*10/100/1000Base-T uplink RJ45 ports (Data) |
|
| Data Transmission Rate | 10BASE-T: Cat3,4,5 UTP (≤100 meters) 100BASE-TX: Cat5 or later UTP (≤100 meters) 1000BASE-T: Cat5e or later UTP (≤100 meters) |
|
| Packet Forwarding Rate | 14.88Mpps | |
| MAC Address Table | 8K | |
| Power Supply | External power adapter, AC100 -240V 50-60Hz, 0.35A | |
| Power Consumption | Standby<6W, Full load<10W | |
| Lightning Protection | Lightning protection: 4KV 8/20us, Protection level: IP30 | |
| Operating Temperature | -20~+55°C, 5%~90% RH Non condensing | |
| Operating Humidity | -20~+55°C, 5%~90% RH Non condensing | |
| PoE | ||
| Protocol | IEEE 802.3 10BASE-T, IEEE 802.3i 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3ab 1000Base-T, IEEE 802.3z 1000Base-X, IEEE 802.3x | |
| Long Distance PoE Transmission | Multi-mode: 850nm/ 0-550m, Single-mode: 1310nm/ 0-40km, 1550nm/ 0-120km | |
| Warranty | ||
| Manufacture Warranty | 01 Year Warranty | |
The ONV ONV-H3008FO 10 Port Gigabit Fiber
Switch is a high-performance networking solution designed for CCTV surveillance
systems, fiber network expansion, and enterprise networking in Bangladesh. This
switch comes with 8 Gigabit SFP fiber ports and 2 Gigabit RJ45 uplink ports,
providing flexible connectivity for both fiber and Ethernet networks. It is
ideal for IP camera systems, NVR installations, and long-distance network
connections where stable and high-speed data transmission is required. With
20Gbps switching capacity and wire-speed forwarding, the switch ensures smooth
video streaming without delay or packet loss, making it a reliable option for
modern surveillance networks.
10-Port
Gigabit Network Connectivity: Equipped with 8 Gigabit SFP fiber ports and 2
Gigabit RJ45 ports, allowing flexible integration of fiber networks and
standard Ethernet devices.
High-Speed
20Gbps Switching Capacity: Provides non-blocking switching capacity of
20Gbps, ensuring smooth data transfer for CCTV video streaming and enterprise
networking.
Stable Video
Transmission for Surveillance Systems: A 2MB packet forwarding buffer helps
maintain stable data transmission and prevents video lag in HD surveillance
systems.
Fiber
Network Expansion for Long-Distance Connectivity: The Gigabit SFP ports
support single-mode or multi-mode fiber modules, enabling long-distance
transmission from 550 meters up to several kilometers depending on the module
used.
Plug &
Play Unmanaged Switch: No configuration is required—simply connect the
fiber modules, IP cameras, or NVR system and the network starts instantly.
24/7
Reliable Operation: Designed for continuous 24/7 operation, ensuring stable
performance for surveillance systems in hotels, banks, campuses, factories, and
commercial environments.
Flexible
Networking for CCTV and Enterprise Systems: Supports Gigabit RJ45 and fiber
port combination, allowing installers to build flexible networks depending on
installation requirements.
The ONV-H3008FO Gigabit fiber switch is widely used
in IP camera surveillance networks, enterprise LAN systems, campus networks,
and commercial security installations because of its stable high-speed
performance and fiber networking support. It helps extend network coverage
while maintaining reliable data transmission for HD video monitoring. If you
are searching for the best fiber switch price in BD 2026 for CCTV or IP camera
networks, this ONV model is a great choice. You can get the best price in BD
2026 from Asiabiz Technology, a trusted supplier of CCTV cameras, IP cameras,
NVR, DVR, PoE switches, fiber switches, and security accessories in Bangladesh.
Frequently
Asked Questions (FAQs)
Q: What is
the ONV-H3008FO price in BD 2026?
A: The
ONV-H3008FO price in Bangladesh may vary depending on availability and
supplier. Contact AsiaBiz Technology for the latest price and stock.
Q: How many
fiber ports does the ONV-H3008FO switch have?
A: This
switch includes 8 Gigabit SFP fiber ports and 2 Gigabit RJ45 ports, making it a
10-port Gigabit fiber switch.
Q: Does this
switch support PoE?
A: The
ONV-H3008FO is a fiber Ethernet switch and does not provide PoE power. It is
mainly used for fiber network expansion and data transmission.
Q: What is
the switching capacity of this switch?
A: The
switch provides 20Gbps switching capacity with 14.88Mpps forwarding rate,
ensuring stable and high-speed network performance.
Q: Which is
the best fiber switch for CCTV networks in BD 2026?
A: For fiber-based surveillance networks, Gigabit fiber switches like the ONV-H3008FO are popular because they provide high-speed transmission, flexible connectivity, and stable 24/7 operation.
